Reliance (WH9-6) Single Element Water Heater Thermostat with E.C.O.
The Reliance (WH9-6) Single Element Water Heater Thermostat with E.C.O. by Reliance is a Water Heater Thermostat product. Available for delivery and in-store pickup at Family Hardware in Cape Coral and Fort Myers, FL.
Estimated subtotal
$23.99
Secure checkout
Easy returns
Shipping Costs
Ships via FedEx
When Will My Order Arrive?
Orders before 12:30 ET Ship Same Day. Otherwise next Business Day.
6 pole connection. 120 V., 208 V., or 240 V. Also used for double element heaters that are wired for simultaneous operation. Replaces No. 7025, and 8025 with Safety ECO (Energy Cut Off) attached and replaces No. WH2-4 or WH5-4, or WH7-2, or WH7-4. Can be used to replace thermostats on most residential electric water heaters. Thermostats are set at 120 F. and are adjustable between 110 F. and 160 F. Thermostats include a Safety ECO, that cuts off all power to the heater should internal tank temperature reach 190 F. (The 9000507, Lower Thermostat, does not require an ECO Thermostat and ECO are UL listed. Fits water heaters with Apcom, Robertshaw, and Therm-O-Disc thermostats. Original part for: A.O. Smith, A.O. Smith Canada, American, GSW, John Wood, Kenmore, Lochinvar, Maytag, Mor-Flo, Penfield, Reliance, Sears, State Industries, U.S. Craftmaster, Whirlpool. Fits: Bradford White, General Electric, Rheem, Richmond, Ruud
